Description
1. Pure Sine Wave Inverter With Double CPU Intelligent Control Technology
2. Build-in 6000 cycles A+ Quality LiFePO4 Lithium Battery 5 Years Service Life
3. No Installation required. Just plug it in
4. MPPT Controller greatly improving the charging efficiency by more than 30%
5. Overcharge protection and over-discharge protection for a longer battery life
6. Convenient and practical 5VDC-USB output port and 12VDC output port
7. Overall automatic protection and alarms including AC output overload short circuit protection etc.
|
Model
|
SPS-500W
|
SPS-1000W
|
SPS-2000W
|
SPS-3000W
|
SPS-5000W
|
SPS-10KW
|
|
Voltage
|
12V
|
24V
|
24V
|
48V
|
48V
|
48V
|
|
Inverter
|
||||||
|
Rated Power
|
500W
|
1000W
|
2000W
|
3000W
|
5000W
|
10KW
|
|
Input Voltage Range
|
220-240V,110-120V (optional)
|
|||||
|
Output Voltage
|
220-240V,110-120V (optional)
|
|||||
|
Output Wave
|
Pure Sine Wave
|
|||||
|
Built-in LifePO4 Lithium
|
640WH
|
1280WH
|
2560WH
|
3430WH
|
5120WH
|
10240WH
|
|
Solar Input
|
||||||
|
Max.PV Power
|
100W*2pcs
|
160W*2pcs
|
160W*4pcs
|
450W*2pcs
|
450W*3pcs
|
450W*6pcs
|
|
Range Of Charging Voltage
|
18-55Vdc
|
30-55Vdc
|
30-150Vdc
|
60-150Vc
|
60-150Vdc
|
60-150Vdc
|
|
Rated Charge Current
|
30A MPPT
|
60A MPPT
|
||||
|
DC Output
|
13.7V
|
27.4V
|
27.4V
|
56.8V
|
56.8V
|
56.8V
|
|
Voltage For High Voltage Protection
|
14Vdc
|
28.5Vdc
|
28.5Vdc
|
57Vdc
|
57Vdc
|
57Vdc
|
|
Low Voltage Protection Voltage
|
12Vdc
|
24Vdc
|
44.8Vdc
|
44.8Vdc
|
44.8Vdc
|
44.8Vdc
|
|
5VDC USB Output
|
2pcs/MAX 2A
|
|||||
|
12VDC Output Ports
|
2pcs/MAX 2A
|
|||||
|
Physical
|
||||||
|
Heat Dissipation/Cooling
|
Temperature control by intelligent exhaust fan
|
|||||
|
Display
|
Digital LCD
|
|||||
|
Electricity Charging
|
12V30A
|
24V30A
|
48V30A
|
|||
